Description
Panel
Specification
|
Description
|
Display panel type
|
23.8 inches IPS, Micro edge LED backlight
|
Viewable image area (diagonal)
|
60.45 cm (23.8 in) widescreen
|
Panel active area (W x H)
|
52.70 x 29.64 cm (20.75 x 11.67 in)
|
Resolution
|
1920 x 1080 at 60 Hz
|
Aspect ratio
|
16:9
|
Viewing angle (typical)
|
Up to 178° horizontal (10:1 minimum contrast ratio)
Up to 178° vertical (10:1 minimum contrast ratio)
|
Brightness (typical)
|
250 cd/m2
|
Contrast ratio (typical)
|
Static
1,000:1
Dynamic Contrast Ratio (DCR)
10,000,000:1
|
Response times
|
5 ms
NOTE: |
Pixel pitch
|
0.2745 mm
|
Default color temperature
|
Neutral (6500 K)
|
Backlight lamp life
|
30,000 hours minimum (to half brightness)
|
Color support
|
Up to 16.7 million colors (with the use of FRC technology)
|
Color gamut (typical)
|
72% (NTSC)
94% sRGB
|
Surface hardness
|
3H
|
Anti-glare panel
|
Yes
|
Flicker free
|
Yes
|
Low blue light capable
|
Yes (user selectable in On-screen Display (OSD) menu)
|
NOTE: Actual performance varies.
User Controls
Specification
|
Description
|
Monitor control buttons or switches
|
Menu/OK
Plus ("+")/Up/Viewing Mode Menu
Minus ("- ")/Down/Information
Exit/Back/Next Input Port
Power
|
User-assignable function buttons
|
10
|
Languages
|
10 (English, Spanish, German, French, Italian, Dutch, Portuguese, Japanese, Simplified Chinese, and Traditional Chinese)
|
On-screen Display (OSD) user controls
|
Brightness, Contrast, Color Control, Input Control, Image Control, Power Control, Menu Control, Management, Language, Information, and Exit
|
Signal interface/performance
Specification
|
Description
|
Native resolution
|
1920 x 1080 at 60 Hz
|
Preset graphic modes (non-interlaced)
|
640 x 480 at 60 Hz
720 x 400 at 70 Hz
800 x 600 at 60 Hz
1024 x 768 at 60 Hz
1280 x 720 at 60 Hz
1280 x 800 at 60 Hz
1280 x 1024 at 60 Hz
1440 x 900 at 60 Hz
1600 x 900 at 60 Hz
1680 x 1050 at 60 Hz
1920 x 1080 at 60 Hz
|
Pixel clock
|
170 MHz (maximum)
|
Vertical frequency
|
50 - 60 Hz
|
Horizontal frequency
|
30 - 80 kHz
|
Video / Other Inputs/cables
Specification
|
Description
|
Connector types
|
(1) HDMI 1.4
(1) DisplayPort (DP) 1.2
NOTE: (1) VGA
|
USB port
|
(3) USB 3.0
(2) Downstream and (1) Upstream
|
Cables
|
(1) VGA 1.8 m (5.9 ft) cable
(1) DisplayPort 1.8 m (5.9 ft) cable
(1) USB Type-B to Type-A 1.8 m (5.9 ft) cable
|
Ergonomics
Specification
|
Description
|
Plug and play
|
Yes
|
Tilt range
|
-5° to +23° vertical
|
Swivel range
|
45°L to 45°R
|
Pivot rotation
|
90° (clockwise and counter-clockwise)
|
Detachable stand
|
Yes (ships detached)
|
Height adjustment
|
150 mm (15 cm)
|
Cable management
|
Integrated
Effortless routing of cables through the stand
|
Color
|
Silver
Facing bezel, side frame, column stand, and foot
Black
Rear cover and stand center trim
|
VESA mount
|
100 mm (3.94 in) with integrated mount
|
Security lock-ready
|
Yes
|
Power
Specification
|
Description
|
Power supply
|
Internal
|
Input power
|
100 - 240 VAC at 50/60 Hz
|
Maximum power
|
38 W
NOTE: |
Typical power
|
21 W
NOTE: |
Energy saving/standby mode
|
0.5 W
|
Power cable length
|
1.9 m (6.23 ft)
|
Physical Specs
- Dimensions (W × D × H)
- Unpacked with stand (highest setting): 53.87 x 20.50 x 33.30 cm (21.21 x 8.07 x 13.11 in)
- Packaged: 62.0 x 40.0 x 27.30 cm (24.41 x 15.75 x 10.75 in)
- Head only: 53.87 x 32.18 x 4.52 cm (21.21 x 12.67 x 1.78 in)
Weight
- Unpacked: 5.59 kg (12.32 lb)
- Packaged: 8.08 kg (17.81 lb)
- Head only: 3.08 kg (6.79 lb)
What's In The Box
Specification
|
Description
|
Monitor and accessories
|
HP EliteDisplay E243 23.8-inch Monitor
AC power cord
VGA 1.8 m (5.9 ft) cable
DisplayPort 1.8 m (5.9 ft) cable
USB Type-B to Type-A 1.8 m (5.9 ft) cable
|
Other contents
|
CD
Documentation
|
Software included
|
HP Display Assistant (with CD)
|
Environmental
Specification
|
Description
|
Temperature
|
Operating
5° to 35°C (41° to 95°F)
Non-operating
-20° to 60°C (-4° to 140°F)
|
Humidity
|
Operating
20% to 80% non-condensing
Non-operating
5% to 95% (38.7°C maximum wet-bulb)
|
Altitude
|
Operating
0 to 5,000 m (0 to 16,400 ft)
Non-operating
0 to 12,192 m (0 to 40,000 ft)
|
Arsenic-free display glass
|
Yes
|
White LED backlights
|
Yes
|
Mercury-free display backlighting
|
Yes
|
Low halogen
|
Yes (except cables)
NOTE: |
Eco-label certifications & declarations
|
ENERGY STAR
EPEAT Gold (registration varies by country/region)
CEL Grade 2
Microsoft WHQL certification (Windows 7, 8, and 10)
TCO certified edge
SmartWay transport partnership (North American countries/regions only)
CE
CB
MSIP
Mexico COC
ICES
ISO 9241- 307
CU
cTUVus
ISC
CCC
VCCI
FCC
BSMI
WEEE
RCM
ErP
S-mark
|
